// Product Advantages
1. Permanent magnet direct drive technology, efficient and stable power generation
Using permanent magnet with low loss stator winding, abandoning gear box transmission, successfully avoid the energy loss caused by gear friction of traditional models, the power generation efficiency is significantly increased by 20% compared with traditional models, and the full power operating efficiency is always stable at more than 92%. Equipped with aerodynamically-certified aerodynamically-optimized reinforced FRP blades for excellent aerodynamic performance, it only needs 2m/s of ultra-low start-up wind speed to start power generation operations. In the area with an average annual wind speed of 6-8m/s, the average annual power generation of a single machine can reach 100,000 degrees, which can meet the electricity demand of 30 households for a whole year.
2. Intelligent adaptive control system, stable operation in all scenarios
Integrate the intelligent master control unit and multi-axis sensor to realize the seamless connection of grid-connected and off-grid dual modes. Using the unique "wind speed - power" dynamic matching algorithm, the blade attack Angle can be accurately and automatically adjusted according to the real-time wind speed, the adjustment accuracy is up to ±0.5°, to ensure that the constant power output can be maintained in the strong wind range of 12-25m/s. At the same time, with the help of electromagnetic unloading technology, the peak current fluctuation is effectively controlled within 5%. With an ultra-wide operating temperature range of -40 ℃~+60℃, it can easily adapt to various complex harsh environments such as high altitude and coastal salt spray, with an average trouse-free time of more than 50,000 hours, and stable and reliable performance.
3. Low maintenance long life design, full cycle cost optimization
The use of mechatronics rotary structure, reducing 70% of mechanical connections, with maintenance-free cycle of up to 5 years of self-lubricating bearings, greatly reducing the daily maintenance needs of equipment, annual maintenance costs compared with similar products reduced by 40%. Steel tower using hot dip galvanizing process, coating thickness ≥85μm, effectively resist corrosion. The design life of the whole machine is up to 20 years, which saves a lot of costs for customers from the perspective of long-term operation.
| Rated power | 30KW |
| Rated voltage | 240V/380V/480V |
| Cut-in wind speed | 3m/s |
| Start wind speed | 2m/s |
| Rated wind speed | 10m/s |
| Safe wind speed | ≤50m/s |
| Wind wheel diameter | 12m |
| Tower height | 20m |
| Blade quantity | 3 |
| Blade material | Reinforced fiberglass composite materia |
| Body material | Fine cast steel |
| Magnet material | N42Sh |
| Generator type | Three-phase AC permanent magnet synchronous generator |
| Control method | Electromagnetic brake + electromagnetic brake |
| Wind direction adjustment | Automatic adjustment of windward angle |
| Life span/Protection | ≥20 years/IP54 |
| Net/Gross | 1000kg/1200kg |
// The following are common application scenarios of GWS-30KW horizontal axis wind turbines:
1. Power lifeline in remote areas
In remote villages and mountains far from the radiation of the urban grid, the construction of transmission lines is not only a huge project, but also a staggering cost. At this time, 30KW horizontal axis wind turbines will show their skills and become the "main force" of independent power supply. These areas are often abundant in wind energy resources, and wind turbines can be fully deployed, efficiently converting wind energy into electricity, stably lighting every lamp in the village, and driving various equipment in small processing plants.
2. Island energy transformation "booster"
For a long time, the island relies too much on diesel power generation, the cost is high, and the environmental pollution problem is increasingly serious. The 30KW horizontal axis wind turbine is specially designed for the complex wind environment of the island, and its strong typhoon-resistant design can stand up in the fierce wind and continue to work steadily. Coupled with efficient energy storage devices, wind turbines generate and store energy at full capacity during the day, ensuring that the island is fully charged at night or when there is no wind. Whether it is the operation of seawater desalination equipment or the daily consumption of electricity for residents, it can be properly met, effectively promoting the island to get rid of excessive dependence on traditional energy, significantly improving the rate of energy self-sufficiency, and moving towards the road of green development.
3. "Golden Partnership" of complementary scenery
In areas with unique solar resources, 30KW horizontal axis wind turbines and solar panels work together to form a wind-solar complementary system, which is a match made in heaven. During the day, the sun is shining, and solar panels are dominant in generating electricity efficiently with sufficient light; When night falls or it is cloudy and light is scarce, the wind generator will quickly "pick up the rod" and continue to deliver electricity to the electrical equipment. The two complement each other, effectively smooth the fluctuation curve of power output, and greatly alleviate the intermittency problem of power generation. In scenic spots, highway service areas and other places, this system is widely used, not only to ensure a stable and reliable power supply, but also to contribute to the cause of energy conservation and emission reduction.
4. "Good helper" in production and life in pastoral areas
The pastoral area is vast, and the power grid is difficult to fully cover. The 30KW horizontal axis wind turbine is convenient and flexible to install, bringing convenience to the household electricity for the herdsmen settlement, allowing household appliances such as televisions and refrigerators to operate normally, and enriching the daily life of herdsmen. At the same time, it also provides stable power for the irrigation pumps and forage processing equipment of the pasture, which effectively guarantees all aspects of animal husbandry production, greatly improves the convenience of herdsmen's life and production, and becomes the right-hand man for the modernization process of pastoral areas.
5. Small industry "energy saving engine"
For industrial sites such as small processing plants and mines that are far from the large power grid and have moderate power demand, 30KW horizontal axis wind turbines are an ideal choice, which can be used as the main power supply or as a supplementary power supply. In wood processing plants, small quarries and other places, it drives the stable operation of various types of equipment, significantly reduces the cost of electricity, enhances the autonomy of industrial production in energy access, and injects strong impetus into the sustainable development of small industries.
// FAQ
Q: Does the wind turbine work well in areas with low wind speeds?
A: GWS-30KW horizontal axis wind turbines have excellent low wind speed start-up performance, and can start power generation at a low wind speed of 2m/s. Through advanced aerodynamic optimization design of the blades, low wind energy can be efficiently captured.
Q: Is it complicated to set up this equipment? Need a professional team?
A: The installation process is relatively complex, and it is recommended that a professional team operate.
Q: What are the routine maintenance tasks? Is it expensive to maintain?
A: Routine maintenance mainly includes regularly checking whether the blades are damaged, cleaning the dust on the generator surface, and checking whether the connection of each component is loose. The annual maintenance cost is reduced by about 40% compared with similar products, which greatly reduces the maintenance burden of users.
