// Product Advantages
1. High performance permanent magnet power generation technology, a leading energy industry
Adopts three-phase AC permanent magnet synchronous generator, tie-in aerodynamic optimization of the FRP blade, wind energy utilization coefficient is higher than the average level, the rated wind speed at 10 m/s stable output power of 1 kw, satisfy ordinary families more than 60% of the daily demand. The all-copper winding and low loss design ensure that the power generation efficiency is maintained at more than 92% for a long time, reducing energy waste.
2. Ultra-wide wind speed adaptation range, continuous power generation in weak wind environment
With industry-leading 2m/s ultra-low starting wind speed (most competitive products need 4-5m/s), it can be started in light weather, with intelligent MPPT maximum power tracking technology, real-time dynamic adjustment of blade Angle and generator speed, and maintain efficient power generation within a wide wind speed range of 5-25m/s. Power generation increased by 30%-36% compared with traditional models. Suitable for plain, coastal and other wind speed fluctuation scenes, to achieve "breeze power generation, strong wind protection" full scenario adaptation.
3. Military grade durable design, 20 years long life
The body adopts reinforced die-cast aluminum frame + hot-dip galvanized anti-corrosion coating, and the blades are tested by salt spray, which can operate stably in extreme temperature difference environment. It can withstand 50m/s strong wind, the key components (bearings, gearbox) adopt a fully sealed maintenance-free structure, the whole machine life is up to 20 years, and the maintenance cost is 30% lower than that of similar products.
4. Quiet operation + intelligent control, power experience upgrade
With bionic blade curvature design and low vibration bearing, the running noise is less than 40 decibels (equivalent to quiet conversation), avoiding sound pollution to residential areas and farms. Integrated 48V intelligent controller, support DC output and AC inverter, built-in overcharge/overdischarge/short circuit protection module, can be directly connected to the home grid or battery, compatible with the parallel use of solar panels, to achieve seamless integration of wind-solar complementary power generation system.
5. Easy installation, suitable for multiple scenarios
Support 30 minutes quick assembly, no professional lifting equipment, one person can complete the roof, tower or ground support installation. Suitable for home backup power supply, off-grid power supply in remote mountainous areas, small base station emergency power supply, RV or ship mobile power supply and other scenarios, with 10-20kWh battery packs, can be continuously supplied for more than 48 hours in a wind-free environment, providing stable energy security for off-grid users.
| Rated power | 1KW |
| Rated voltage | 48V/96V |
| Cut-in wind speed | 3m/s |
| Start wind speed | 2m/s |
| Rated wind speed | 10m/s |
| Safe wind speed | ≤50m/s |
| Wind wheel diameter | 2.8m |
| Tower height | 10m |
| Blade quantity | 3 |
| Blade material | Reinforced fiberglass compositemateria |
| Body material | Reinforced die-cast steel |
| Magnet material | N42Sh |
| Generator type | Three-phase AC permanent magnet synchronous generator |
| Control method | Electromagnetic brake + electromagnetic brake |
| Wind direction adjustment | Automatic adjustment of windward angle |
| Life span/Protection | ≥20 years/IP54 |
| Net/Gross | 28kg/30kg |
// The following are common application scenarios of GWS-1KW horizontal axis wind turbines:
1. Home power supplement and backup power supply
Suitable for rural, suburban and independent houses, can be off-grid operation or parallel with the grid, to meet the lighting, home appliances, heating and other daily electricity needs. With 10-20kWh battery set, sustainable power supply for more than 48 hours when there is no wind, effectively reduce electricity costs, especially suitable for frequent power outage areas as emergency energy security.
2. Off-grid power supply in remote areas
Provide independent power for areas without grid coverage such as mountains, islands and grasslands, and support basic power consumption such as water pumps, LED lighting and satellite equipment. 2m/s ultra-low starting wind speed ADAPTS to the breeze environment, solves the problem of electricity difficulty in remote areas, and helps rural revitalization and distributed energy construction.
3. Small farms and ranches
It can supply power for irrigation system, livestock drinking water equipment, greenhouse temperature control and monitoring system, and support the simultaneous operation of multiple equipment. Compatible solar panels form a wind-solar complementary system to cope with weather fluctuations, ensure the continuity of agricultural and animal husbandry production, and reduce the dependence on diesel generators and operating costs.
4. Communication base station and monitoring equipment
It provides stable power for 5G base stations, meteorological monitoring stations and security cameras in remote areas, and is designed to withstand 50m/s strong winds and adapt to harsh environments such as coastal and plateau environments. The maintenance-free structure reduces the frequency of manual inspection, and the intelligent controller automatically optimizes the output to ensure the reliable operation of the equipment.
5. Mobile scenarios and off-grid devices
Suitable for RV, yacht and field exploration equipment, lightweight body supports quick installation without professional tools. The inverter can directly drive 220V appliances to meet the power needs of mobile scenarios such as camping and fishing operations, and achieve flexible power supply with "installation and use".
6. Environmental education and small demonstration projects
As a renewable energy teaching aid for schools, ecological parks and science popularization bases, low noise (<40dB) and visual power generation process visually demonstrate the principle of green energy. Support grid-connected display of real-time power generation, help promote the concept of carbon neutrality, suitable for small environmental projects and enterprise ESG practice.
// GWS-1KW Horizontal axis wind turbine usage guide
1. Do not disassemble the equipment by yourself. Contact the after-sales service when the equipment fails.
2. Without authorization, no unit or individual may, security and performance of equipment structure design changes.
3. When using this equipment should follow the relevant laws and regulations, respect the legitimate rights and interests of others.
4. Wind generator connected to the controller must first connect the battery.
5. Not according to the requirements of this manual operation after a fault, such as problems or are beyond the scope of the warranty.
// FAQ
Q: Can power be generated normally in areas with low wind speeds, such as plains or cities?
A: With 2m/s ultra-low starting wind speed, with intelligent MPPT technology, efficient power generation in 5-25m/s wide wind speed range, to meet the daily electricity supplement.
Q: Can it be connected directly to the home grid? Need additional equipment?
A: Support off-grid/grid-connected dual mode: directly charge batteries or drive DC devices when off-grid; Connected to the grid, a dedicated inverter (optional) is required to convert 48V DC to 220V AC, seamlessly connected to the home grid, and the intelligent controller automatically adjusts the output.
Q: What capacity battery is needed? How to choose?
A: It is recommended to match 10-20kWh battery packs, and the specific capacity can be adjusted according to the power demand. When there is no wind, the 10kWh battery can support the average family 8-12 hours of electricity, and the controller has overcharge protection to extend the battery life.
