Industry-leading thermal stability: Adopting advanced liquid cooling technology to minimize temperature difference between batteries, greatly improving battery consistency, service life and State of Health (SOH).
Superior reliability & safety: Maintains optimal operating temperature even under extreme conditions, ensuring long-term stable operation and reducing thermal-related risks.
Easy deployment & maintenance: Pre-integrated modular design with flexible layout enables quick installation, simplified maintenance and adaptation to various site environments.
Optimized Total Cost of Ownership (TCO): Boosts operating efficiency and extends cycle life. It cuts down energy waste and maintenance costs to achieve lower overall ownership expenses.
Category | Item | Parameter |
|---|---|---|
Battery Parameters | Cell Type | 3.2V/280Ah LFP Lithium Iron Phosphate |
Rated Voltage | 832V | |
Voltage Range | 650~949V | |
Rated Power | 105kW | |
System Capacity | 233kWh | |
Configuration | 1P260S | |
Rated Frequency | 50Hz | |
Charge & Discharge Rate | 0.5C | |
System Parameters | AC Rated Voltage | 400VAC |
AC Wiring Mode | 3P+N+PE | |
Heat Dissipation Method | Intelligent Liquid Cooling | |
Converter Cooling Method | Forced Air Cooling | |
Fire Protection System | Composite detectors (smoke, temperature, flammable gas); audible & visual alarm; cabinet & cluster spraying; perfluorohexanone fire extinguishing agent; water fire protection | |
Protection Level | IP54 | |
Communication Mode | CAN, RS485, Ethernet, 4G | |
Cycle Life | ≥6000 cycles | |
Product Weight | Approx. 2.7 Tons | |
Product Dimension | 1000×1400×2415 mm | |
Environmental Conditions | Installation Way | Indoor / Outdoor installation (tent shelter recommended) |
Ambient Temperature | -20°C ~ 55°C | |
Humidity Range | 0-95% (non-condensing) | |
Altitude | Max. 3000m; power derating required above 3000m |
Q1: Is the installation complicated?
A: Installation, wiring and grid-connected commissioning must be completed by licensed professional electricians and energy storage installation engineers. This is an 832V high-voltage energy storage system involving high-voltage wiring, PCS commissioning, earthing protection and fire linkage. Unauthorized installation is strictly forbidden to avoid electric shock, equipment damage and safety accidents.
Q2: Is the high-voltage system safe? What protections does it have?
A: Equipped with multi-level BMS protections including over-voltage, over-current, over-temperature and short-circuit protection. It is fitted with automatic perfluorohexanone fire extinguishing system and reaches IP54 outdoor protection grade.
Q3: Does it support grid-connected and off-grid switching?
A: It supports grid-connected peak shaving and valley filling, as well as off-grid emergency power supply, realizing seamless switching when mains power cuts off.
Q4: Can it work in high and low temperature environments?
A: Built-in liquid cooling temperature control system supports stable full-power operation from -20°C to 55°C, suitable for severe cold and high temperature scenarios without power derating.
Q5: Does it require daily maintenance?
A: No daily maintenance needed. Only annual routine inspection is required, including wiring tightness, heat dissipation ventilation, cabinet cleaning and fire system status check.
