Modular & Expandable Design
Multiple module cabinets can be connected in parallel to realize cluster control. The system capacity can be adjusted flexibly to meet changing application demands.
High Reliability & Safety
Equipped with a precise fire suppression system adopting gas and underwater fire extinguishing methods. It applies the one cabinet per rack protection strategy, greatly improving system availability and safety.
Low Operation & Maintenance Cost
It minimizes overall operation and maintenance expenses. Unattended operation is supported to reduce labor costs.
Intelligent Management & Control
Adopts multi-scenario intelligent strategies to achieve optimal performance under various working conditions. Integrated with cloud architecture for efficient data management and rapid response. Mobile monitoring is available to realize real-time status viewing anytime and anywhere.
High Degree of Automation
Comprehensive intelligent and remote functions enable fully unattended automatic operation.
Category | Item | Parameter |
|---|---|---|
Battery Parameters | Cell Type | 3.2V / 314Ah, LFP |
Rated Voltage | 1331.2V | |
Voltage Range | 1040 ~ 1518.4V | |
Rated Power | 210kW | |
System Capacity | 418kWh | |
Cell Configuration | 1P416S | |
Rated Frequency | 50Hz | |
Battery Chamber Temperature Control Accuracy | ±0.5°C | |
System Parameters | AC Rated Voltage | 400VAC |
AC Wiring Mode | 3P+N+PE | |
Heat Dissipation Method | Intelligent Liquid Cooling | |
Converter Cooling Method | Forced Air Cooling | |
Fire Protection Solution | Composite detector (smoke, temperature, flammable gas); Acoustic and optical alarm; Individual & cluster sprinkler fire suppression; Fluoroketone fire extinguishing agent; Underwater fire protection | |
Protection Level | IP54 | |
Communication Mode | CAN, RS485, Ethernet, 4G | |
Cycle Life | ≥6000 times | |
Product Weight | Approx. 4.2T | |
Product Dimension | 1350×1400×2400mm | |
Environmental Conditions | Installation Method | Indoor / Outdoor installation (Tent shelter recommended) |
Ambient Temperature | -20°C ~ 55°C | |
Humidity Range | 0~95% (Non-condensing) | |
Altitude | 3000m; derating required above 3000m |
Q1: Is the installation complicated?
A: No assembly, complicated wiring or dedicated machine room construction is required. It can be directly installed outdoors on the ground. Ordinary electricians can complete docking work, with the whole process simple and efficient.
Q2: Does it support grid-connected and off-grid switching?
A: Full automatic switching is supported. It seamlessly switches to energy storage power supply the moment mains power cuts off, ensuring uninterrupted operation of connected equipment.
Q3: What type of cell and heat dissipation method are adopted?
A: Lithium iron phosphate cell with full-area liquid cooling, featuring uniform heat dissipation and precise temperature control.
Q4: Can it work in high and low temperature environments?
A: Discharge temperature: -25℃ ~ +60℃; Charging temperature: -20℃ ~ +55℃.
Built-in liquid cooling constant temperature and active preheating system automatically preheats cells under low temperature. It causes no capacity attenuation or charging limitation, supporting stable outdoor operation in northern winters.
Q5: Does it require daily maintenance?
A: Daily maintenance is not needed. Only simple regular inspection every half a year or one year is required:
1. Check cabinet appearance for damage and tightness of wiring terminals;
2.Clean sundries around the equipment to ensure smooth ventilation and heat dissipation;
3.Verify normal operating parameters on the background platform.
